Design Nominees
Dewpointmeter

Dewpointmeter

by vasthi instruments

159
Categories Tags
Description

The  Online Dew point meter can be perceived as the temperature at which the water vapor content in a gas arrives at a soaked state. It is one of the approaches to communicate the outright stickiness of a gas. It may very well be seen that the dew point temperature is a unit system for measuring the moisture content of a gas. The dew point meter is an instrument that measures the absolute moisture content of gas dependent on this unit system.

An Embedded microcontroller-based precision instrument to help to ensure optimum operation of drying equipment.Ideal for precise Monitoring of moisture or Dew point in air or gas output from dryers systems or processes. Continuous monitoring of dewpoint results in reduced maintains cost and downtime caused by separated moisture. The main cause of corrosion in pneumatic systems. The analyzer uses a highly accurate    Aluminium Oxide sensor and is an economic alternative to the chilled-mirror dew point type Meters. It utilizes embedded micro control-based circuits to give a direct-read out in dew point or other units and other units corresponding to sensor output-based and Psychometric equations. To achieve high accuracy it uses temperature compensation over the complete operational range.

THE SAMPLING SYSTEM CONSISTS OF

  • ISOLATING VALVE
  • Drain Valve
  • VACUUM PUMP
  • DUST FILTER
  • FLOW INDICATOR

FEATURES :

SPECIAL FEATURES OF ONLINE DEW POINT ANALYSER :

  • Microprocessor-based instrument.
  • Digital Graphical Display Measuring range ‐80° to +30° C dew
  • point & other ranges also available on client requirement.
  • Samples compressed air up to 12 Kg/cm.
  • Pressure and up to 95°C temperature can be measured directly.
  • Quick disconnect fitting, desiccant test.
  • Handy and lightweight.
  • Inbuilt thin film water vapor sensor.
  • Optional RS ‐ 485 computer interface & data logger.

ONLINE DEW POINT METER ANALYZER ADDITIONAL FEATURES

  • Computer Interface: RS‐485 or USB
  • Data Logger: 1 Megabyte, Non‐Volatile Memory
